Here is a comprehensive guide to the applications and functionalities you gain access to when you purchase IDEA StatiCa Detail.

Please note that this information is valid from July 1, 2023, and replaces the previous product packages. You can contact us if you need to speak about the previous packages.

Detail application


Geometry
Details: dapped ends, openings, hangings, frame joints
Walls, deep beams, corbels, diaphragms, pier caps, general detail
Geometry and reinforcement import from DXF file
Prestressing - pre-tensioned, post-tensioned detail
Imperial rounding
Realistic reinforcement layouts
Analysis and code-check
Topology optimization
ULS checks – stress and strain in concrete, reinforcement, anchorage stress
SLS checks – crack width, crack directions, stress limitation, deflection
Limited stress check
Long-term losses
Support of regional code ANSI/AISC 360-22
Output
Customized report including export to PDF, Word
2D drawings export
Bill of material

BIM links


BIM links – Checkbot
RFEM/RSTAB. AXIS VM, SAP 2000, Robot Structural Analysis, ETABS, STAAD PRO
BIM links – IDEA Designer
Midas Civil/GEN, AXIS VM, SCIA Engineer
BIM links - direct API to the Beam application
Advance Design, AXIS VM, RFEM/RSTAB, Robot Structural Analysis, SAP 2000

The current BIM link versions

Localization


Supported codes
EN 1992-1-1, EN 1992-2, EN 1992-3; national annexes CZ, SK, AT, BE, DE, UK, NL, PL, SG, SIA 262, and ACI
Supported languages
English, German, French, French, Spanish, Polish, Hungarian, Russian, Dutch, Italian, Romanian, Spanish, Chinese, Czech, Slovak
