I-sections with stub
Moment connection of a horizontal rolled I-section beam connected to the column using asymmetrical haunched stub. The beam is connected to the stub via endplates with bolts. Such a connection is able to transfer axial and shear forces, and bending moments in the horizontal and vertical planes. Modeled and analyzed in the IDEA StatiCa Connection application.
