Different shear force values in bolts

Jul 15, 2019

| Author: Ondrej Fridrich

Steel

Connection

Bolts

This article is also available in:

Surprised, that the results of the bolt shear force analysis differ from what you expect? This is very often caused by the additional distribution of the shear force to more shear planes along with the bolt when the bolt goes through more plates.

The number of shear planes differ from the analytical approach only because of the FEM code-check approach.

See a nice example from everyday engineering practice and explanation of such case on one of our webinars.

Put IDEA StatiCa to the test – Start your FREE trial and enjoy 14 days of the full version!
